Pure Calcium Cored Wire
Pure Calcium Cored Wire is a high-performance secondary metallurgy consumable engineered for deep-melt calcium injection. By delivering solid, ultra-pure calcium directly into liquid steel without introducing iron powder or unwanted tramp elements, it optimizes inclusion morphology (turning solid Al₂O₃ into liquid calcium aluminates), minimizes nozzle clogging, and improves castability.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Pure Calcium Cored Wire is a high-performance secondary metallurgy consumable engineered for deep-melt calcium injection. By delivering solid, ultra-pure calcium directly into liquid steel without introducing iron powder or unwanted tramp elements, it optimizes inclusion morphology (turning solid Al₂O₃ into liquid calcium aluminates), minimizes nozzle clogging, and improves castability.
Technical Specifications
|
Product Name |
Pure Calcium Cored Wire |
|
|
Core Material |
Solid Pure Calcium Strip (Purity ≥ 98.5%) |
|
|
Sheath Material |
Cold-Rolled Low-Carbon Steel Tape |
|
|
Standard Wire Diameter |
9.0 mm / 10.0 mm / 13.0 mm (Tolerance: ±0.2 mm) |
|
|
Calcium Weight / Meter |
52 g/m – 115 g/m (per client specification) |
|
|
Coil Weight Range |
1,000 kg – 2,500 kg per coil |
|
|
Coil Dimensions |
ID 600–800 mm; OD 1,100–1,300 mm |
|
|
Compatibility |
Standard high-speed automated cored wire feeders (100–300 m/min) |
|
Key Technical Advantages
No Tramp Element Addition: Eliminates iron powder or foreign fillers to maintain strict liquid steel purity standards.
Deep-Melt Penetration: High-density pure calcium core reaches the bottom of the ladle before vaporization, increasing calcium yield over CaFe wires.
Alumina Inclusion Modification: Reacts directly with solid Al₂O₃ inclusions to form liquid calcium aluminates (12CaO·7Al₂O₃), preventing tundish nozzle clogging.
High-Speed Feeding Integrity: Cold-rolled steel sheath prevents wire buckling, breaking, or premature seam opening at feeding speeds up to 250 m/min.
Targeted Applications
Steelmaking Processes: Ladle Refining Furnace (LRF), RH Degasser, Continuous Casting (CC).
Critical Steel Grades: Bearing steel, pipeline steel (API grades), spring steel, high-strength low-alloy (HSLA), and automotive structural steel.
Customization Capabilities
|
Customization Item |
Tailoring Options |
|
Wire & Core Specs |
Wire diameter, sheath thickness, and calcium weight per meter |
|
Coil Dimensions |
Inner/outer diameters and coil height matched to customer pay-off stands |
|
Packaging & Protection |
Vacuum-sealed inner packing, steel cages, or wooden pallets |
|
Branding & Logistics |
OEM service, client-specific labeling, and custom barcoding |
Packaging & Logistics
Inner Protection: Sealed with waterproof PE film and outer shrink-wrap for moisture protection.
Structural Support: Secured inside heavy-duty steel cages or on heat-treated export wooden pallets.
Transport Suitability: Engineered for long-distance ocean container shipping.
Quality Control & Verification
Every production lot undergoes process monitoring and physical/chemical quality checks prior to dispatch:
Core Uniformity: Dimensional tolerance and core filling consistency monitoring.
Purity Check: Chemical composition analysis of the pure calcium core.
Pre-Shipment Inspection: Visual, weight, and packaging integrity checks before loading.
Why Partner with Anyang Jingfengyuan Ferroalloy?
31-Year Metallurgical Lineage: Established in 1995, we leverage over three decades of manufacturing experience and 22+ senior engineers to offer tailored alloy ratios and tight tolerance controls.
Scalable Output & Fast Delivery: 80,000+ m² manufacturing base with 8+ dedicated production lines, ensuring an annual output of tens of thousands of tons for bulk orders.
Advanced & Mechanized Production: Equipped with upgraded medium-frequency induction furnaces and fully automated workflows for consistent chemical uniformity.
Certified Quality Assurance: Full batch traceability under ISO 9001, ISO 14000, and GJB 9001 standards, backed by complete in-house lab testing.
Global Logistics & Export Reach: Proven export track record with reliable fulfillment, serving industrial clients across 86+ countries.
FAQ
Q: What is the calcium recovery rate compared to standard CaFe cored wire?
A: Pure calcium wire offers deeper melt penetration before vaporization, typically delivering a calcium recovery rate between 20% and 30% depending on ladle depth and feeding speed.
Q: What feeding speed is recommended for this cored wire?
A: It operates reliably on standard automatic wire feeders at speeds between 120 m/min and 250 m/min, depending on melt temperature and ladle height.
Q: How do you prevent internal calcium oxidation during ocean transit?
A: Each coil is sealed with a moisture-proof PE inner liner, desiccants, and outer shrink wrapping to eliminate humidity exposure and prevent core degradation.
Q: How is coil dimensional tolerance controlled for automated pay-off systems?
A: Wire diameter tolerance is kept strictly within ±0.2 mm, and coil outer/inner diameters are customized to prevent line jamming in automated feeding cages.
Q: What is the typical lead time for a standard 20ft container order?
A: Standard specifications ship within 10–15 business days following order confirmation and deposit receipt.
